You need flexible I/O systems for your facilities u-remote offers more performance and reduces complexity
Let’s connect.
Machine automation with clear added value
u-remote combines powerful technologies with short
project durations
You want to perform your machine development operations – from the automation
concept to the stable machine operation – in such a way that they are fast, high-
performance, smooth and deliver identifiable added value for your
customers. The decisive factors for your project‘s success are consistently efficient
processes and unique functions.
With u-remote you‘re laying the foundation for this. By implementing powerful and
easy-to-use signal connection components, you will reap early on the advantages
for installation work, machine commissioning and subsequent service applications
at your customers‘ premises.
From planning to operation, u-remote allows you to speed up all work processes
and opens up new possibilities in panel building. It is the perfect response to
growing complexity in machine and factory automation thanks to its powerful
flexibility and simple handling.
Our formula: “More Performance. Simplified. u-remote.“
u-remote – the perfect response to growing complexity
Discover the benefits of flexible system approaches
u-remote offers the perfect solution for all common areas of application
within machinery construction. Whether it’s used as a pure panel
system, in mixed IP20 and IP67 applications, or even positioned directly
in the field for signal connection, u-remote grants you complete freedom
to create a flexible I/O architecture and gives you the benefits of an
integrated complete system.
Maximum efficiency in the panel
The only things that are large about u-remote are its savings potential
and the system performance. With the most innovative I/O system
on the market, you can plan your panels to be a whole size smaller.
The modular set-up makes system design easier, and the installation
process is sped up. u-remote not only makes your machines more
affordable, but also more efficient in every respect.
One system, two protection classes – fully integrated
It is very rare for pure IP20 or IP67 signal connections to be needed in machine
automation. With u-remote, you will find that I/O modules are connected directly
to the panel system in a highly flexible, fully integrated and fieldbus-independent
manner. Soon, you will no longer need to use expensive IP67 gateways, and you
will be able to design your automation solution so that it is far more efficient and
comes from a single source too.
High-performance decentralization
As it is a small and multiprotocol-capable system, you can use u-remote wherever
you need high performance directly in the field. Whether you’re communicating
via an I/O-Link or transmitting unprecedentedly high levels of power, design your
decentralized system architecture with u-remote so you are well-equipped for ever-
growing automation requirements in the future too.
Maximum efficiency in the panel
The only things that are large about u-remote are
its savings potential and the system performance
Smarter automation specified in a simpler way
u-remote simplifies your planning activities and offers unique functions
By coming up with new ideas and technologies and delivering the highest connection density
on the market, we simplify the planning process for you and provide you with plenty of
reserves for the future. Implement your customers’ requirements in a perceptibly simpler and
quicker manner. u-remote changes the way you work for this purpose. Your system design
is simplified. Your automation design is made more flexible. And your systems become more
powerful.
More connections on a narrower width
Up to 32 connections on just one module – that‘s got to
be a world record! Connecting eight individually pluggable
4-conductor sensors in the tightest of spaces is child‘s play.
And you even reduce the number of I/O modules required
for signal connection.
Simpler planning
Speed up your selection process: with a wide diversity of
variants due to parameterization, not a multitude of
modules. For you, this translates into only one part number
per module, a simplified module selection process and fewer
spare parts stored on stock.
Unique separation
It‘s a feature you‘ll only find with u-remote: a separate I/O
supply via two highly robust 10 A current paths. You reduce
the planning effort, as you no longer have to perform any
consumption calculations. Flexibly distribute the I/O modules
according to the logical structure of your sensor and actuator
architecture and save power-feed modules at the same time.
Configured to be thinner
With a module width of just 11.5 mm, u-remote is thinner than any other I/O system. And because intelligent miniaturization even creates space for more innovations, it now comes with up to 32 connections per module. So you have space left over for flexibility and solutions that save money.
No space for efficiency losses
u-remote enables the most miniature of system solutions
that deliver maximum performance
Handle your projects with maximum performance. u-remote speeds up your installation
process and makes your machines start up faster. The seamlessly pluggable system
means that you can rely on your intuition and trust that there will be no errors.
Consistent minimization of errors
u-remote‘s modular design makes for shorter machine
start-up. The intuitive handling, seamless pluggability and
single-row connection strip make your work easy and reduce
cabling errors – even when you’re working at high speeds.
Simply plug and go
The fastest way to productive operation: Connect sensors
and actuators with pre-assembled cables. You save time,
improve usage and handling and minimize the error rate.
It‘s ideal, especially for decentralized sub-assemblies and
tight spaces.
Direct insertion – direct savings
All you have to do is inserting the conductor into the
clamping unit until it stops – job done. Our “PUSH IN“
technology not only makes cabling twice as fast for you, but
also offers you uncompromised connection safety.
Clear colors, clear functions
Easy working thanks to an innovative color concept. You
can identify all key functions at a glance and the colored
pushers guarantee intuitively correct working. The extensive
range of marking options also reduce the error rate.
Notably improved production performance
u-remote significantly increases your machines‘ operating availability
Score top marks from your customers with maximum machine availability. u-remote is the
most user-friendly I/O concept on the market that you can use to combine high-performance
automation with optimum system handling. This gives your machines a convincing range of
functions, decisively minimizing the time and effort involved in service and maintenance.
Minimize machine downtimes
The machine may be at a standstill,
but communication is still ongoing:
u-remote is completely hot-swap-
capable. Replace the electronics
without the need to switch off the
I/O system. A safe solution to keep
machine downtimes as short as
possible.
Respond faster thanks to
integrated diagnostics
The integrated u-remote web server
enables start-up in sections even before
machinery is commissioned. Shorten
production downtimes by making use
of unique fast error identification with
plain-text diagnostics.
Immediately identify errors
Error diagnosis has never been so
easy: You can localize errors instantly
with an LED directly on the channel
and status indicators on every module.
An indispensable benefit for secure
commissioning and rapid system
maintenance.
Smart support
Thanks to the printed QR code, you
can access installation instructions
and technical data online. The direct
link takes you to all the key information
about the scanned component.
Integrated safety for both people and machines
u-remote offers swift restart following a fault
Communicative systems such as u-remote form part of the future in factory automation.
For safety, this means that even after triggering an emergency stop, it is still possible to call up
the system’s current status – regardless of how big the safety application is.
With u-remote, a reliable machine shutdown is guaranteed while keeping the sensors active.
And after maintenance, you can restart system operation immediately.
Integrated safety without a safety control
Implement safety solutions by connecting them to the
control. All you have to do is simply position them directly
upstream of the corresponding standard output modules.
And that’s without the need for costly safety PLCs featuring
appropriate outputs or the additional use of safety relays. By
safely shutting down the output current path, you switch off
actuators selectively and, at the same time, keep the sensors
fully active. You can therefore send the machine status to
the control at any time, and it quickly takes over the restart
operation once the problem has been rectified.
• Unique on the market: u-remote safe power-feed modules
• Cascadability of safety circuits
• Safe switch-off of standard output modules
Safely control complex systems using
modernfieldbus technology
Use u-remote to connect distributed safety equipment to
form a fully cooperating safety system, which is monitored
using a centralised safety control. You can ideally integrate
the safe u-remote input and output modules in decentralised
architectures to selectively switch off parts of the production
as required.
• PROFIsafe modules for the PROFIBUS
and PROFINET fieldbuses
• Fail Safe over EtherCAT (FSoE)
is designed for EtherCAT
• Smallest possible safety I/O solution –
highest functional density available
• Safe 4DI-4DO modules combine various
safety functions on only 11.5 mm width
• Easy system configuration due to less variants
of safe I/O modules
Automate production systems in an integrated
way with multiple protection classes
u-remote allows for an integrated signal connection
in IP20 and IP67
System design to meet individual needs
u-remote guarantees complete information consistency in IP20 and IP67
The growing decentralisation in automation requires more and more flexible solutions. The signal
connection is established close to the sensors and actuators, meaning that fewer lines are required and less wiring work needs to be carried out. However, as it is not usually possible to establish pure IP67 connections, IP20 systems are still needed to be integrated.
With u-remote, you can now establish both IP20 and IP67 signal connections within a single
I/O system. The innovative gateway module that allows for the direct connection of up to
15 I/O modules in the field means that separate and expensive IP67 fieldbus components become redundant. This tangibly increases the flexibility.
120 sensors on a mere 11.5 mm
15 subbus modules with a total cable
length of up to 50 m can be connected
on an IP20 gateway measuring a mere
11.5 mm wide. This is a feature that’s
completely unique to u-remote. This
innovative solution means that there’s
no need for expensive IP67 fieldbus
gateways for applications with field
and switching panel installations.
Just switch on and go!
Automatic addressing ensures that
the subbus modules are immediately
detected after switch-on. Modular
device master files make for simple
project planning.
Ready for operation earlier on
The more consistent web server
display for IP20 and IP67 modules
makes it easier to carry out
parameterization, input and output
simulation and system diagnostics.
Free alignment
The space-saving modules that
make up our IP67 system allow for
installation in even the smallest of
spaces. One unique feature is that the
extremely light modules can be fitted
in two different directions – which
is perfect on moving parts of your
application.
High-performance decentralization
u-remote in IP67 for more flexible
automation solutions
Higher performance and more flexible automation
u-remote simplifies system design in the field
u-remote’s new IP67 family combines all the field benefits offered by u-remote IP20
in a device with an increased degree of protection and is perfectly equipped for signal
connection outside of the panel.
It demonstrates a high degree of flexibility in terms of the connection options with IO-Link
and scores top marks with a variable power supply. Another impressive feature of IP67
is its multiprotocol capability. For you, this translates into less effort, fewer costs and
maximum performance at the same time.
Usable around the globe
u-remote offers you maximum flexibility as regards connectivity.
For the power supply, opt for either a 7/8” connection or an
M12 connector with L-coding.
Active communication in the field
Use an I/O-Link to significantly improve your
sensors’ and actuators’ parameter and diagnostic
properties. You will find four type A and four type
B ports each on one module in u-remote. These
firstly enable connection of actuators of up to 2 A.
Each port can be configured as an input or an
output too.
Adjust a protocol instead of swapping a
module
Whether you’re using PROFINET or EtherNet/IP,
u-remote’s multiprotocol function allows you to
plan a remote I/O family but still lets you remain
flexible in your choice of fieldbus.
Higher performance – less effort
Increase your I/O system’s feed-in to 16 A with
u-remote and, as a result, connect even more
consumers in a line and thus significantly reduce
the time and effort needed for wiring.
High performance wherever it’s needed
u-remote cuts an impressive figure due to its robustness,
compact design and low weight
Decentralizing machine automation can prove challenging for I/O systems’
mechanical properties. Indeed, they should offer high performance. But at
the same time, they must remain robust, small and as light as possible, so
they can be put to good use on moving machine parts.
u-remote meets these requirements with a sophisticated complete concept,
which means the innovative system can be put to widespread use.
Robust design
The IP67 modules from u-remote measure up to the most stringent robustness requirements. The fully encapsulated zinc
die-cast enclosures prove extremely reliable wherever resistant signal distributors are needed.
Top performance despite temperature fluctuations
As an IP67 system, u-remote is well-protected against water
and particles and can be used in a temperature range of
-20°C to +70°C
Productivity in a very confined space
Measuring 30 mm and 60 mm wide, u-remote
can be installed both in confined spaces and on
common profiles. What’s more, the modules are
counted among the smallest in their class and are
a good 20% lighter than similar rival products on
the market.
Simpler planning, faster operation
u-remote simplifies your processes
Convenient parameterization and fast plant servicing
The u-remote web server speeds up start-up and maintenance work
Quick and error-free start-up is becoming increasingly important in the area of modern machine
construction. Process sequences need to be simulated before the final machine commissioning,
and decentralized I/O solutions need to be tested for correct functioning. Inputs and outputs need to be checked to ensure that they perform correctly, and configurations need to be implemented and parameters set. These tasks are usually performed using special software tools, which are used to test the performance of the application and to check that the remote I/O station has been installed correctly. These tools are also used to diagnose and locate process errors during subsequent operation, in order to ensure that repairs are carried out as quickly as possible and without any long downtimes.
With u-remote, powerful software for start-up, status monitoring and error diagnosis is already
integrated in the I/O system. The software is accessed via the web server installed on the fieldbus
coupler, making it accessible via any standard Internet browser. The I/O station can be parameterized before a control unit is even connected, and status information and diagnostic and process data can easily be accessed on the station. Settings can also be directly changed, tested and stored for subsequent series installations.
u-remote makes it really easy to start up, parameterize and carry out diagnostics on the remote I/O station via an Internet browser. It is a particularly time and cost-efficient system, and there is no need for any special hardware or software.
Intuitive thought
The new web server design stands out
thanks to its extremely user-friendly
operation. The clear structure makes
it easy to access all of the system
functions, and the swipe functionality
makes for simple navigation on mobile
touch-operated devices.
Status monitoring and diagnostics
Whether on site via USB or via remote
access with a fieldbus interface – the
u-remote web server means that you
can access system status information
or diagnostics results at any time. The
information can be easily viewed via
web browser without the need for
any special hardware or software,
which helps to create transparency
and to make error diagnostics and
rectification easier.
Simpler installation tests
The option to force inputs and outputs
means that processes and procedures
can be simulated even if a PLC is not
connected, thus allowing for multiple
work steps to be performed in parallel.
This significantly reduces the amount
of time required prior to machine
startup, while also allowing for
installation errors to be identified at an
early stage.
Quick series configuration
The parameterization of your u-remote
station can be stored as a file and then
uploaded in order to be transferred
to other u-remote stations. This
significantly reduces the configuration
time required for series production,
while also preventing input errors.
Useful tool tips help you work out what
information to enter.
Simplify your system planning processes
and prevent configuration errors
The u-remote configurator supports your engineering process
A superior tool for your planning process: Assemble your complete I/O system
the quick and easy way with the u-remote configurator.
From the DIN rail, over the coupler, to the modules, the configurator offers you
the best practice variation or alternative system components upon request –
always perfectly coordinated to your application.
Save yourself time and effort:
• Complete system configuration via one interface
• Automatic testing of all the planned stations
• Display and rectification of configuration errors
Save yourself work
Naturally included in our professional planning tool: For a better overview, you can
display the dimensions, product information and comments on individual modules
and module groups. Also, the configurator automatically creates a detailed list of
part numbers, planning data and standard configurations for you.
With just one click of the mouse, you can request a non-binding quotation for your
customized u-remote configuration.
Put through its paces and incorporated in your system
Weidmüller provides you with active support in your projects
Realize your full potential with the help of our experts
u-remote is extremely easy to implement – both as part of completely new
projects and during re-designs and system optimisations to existing machine
concepts. But Weidmüller won‘t leave you alone in this regard. Because we
want to make your work on your projects as simple as possible. You benefit
from our wide range of advisory and support services.
Our experienced application specialists will be more than happy to develop
additional optimization opportunities in complex system architectures
together with you.
Ask for product samples and
experience the benefits for yourself!
Experience the convincing concept of u-remote with your own
eyes: ask for a personal product sample or a fully functional
u-remote test station that you can use to put our system through
its paces today.
You’ll be inspired by u-remote’s simple handling, its high
system performance and its efficient and flexible potential uses.
