Industrial Ethernet
Dual SIM Security Router Solution from Weidmüller
Reliable for network segmentation, firewalling, and remote access
Features and Benefits
• LTE Cat.4 with up to 150Mbps downlink and 50Mbps uplink data rates
• Dual mini-SIM card from different Network providers for redundancy
• 2x 10/100Base-T(x) Ethernet ports
• PoE power input available with 1kV isolation
• 1x RS-232/422/485 Serial port in DB9 connector
• High Speed Wireless Connectivity: 802.11 b/g/n WLAN Wi-Fi interface with up to 150Mbps bandwidth
• DHCP server and DHCP Relay exclusively for LAN network devices
• OpenVPN for secured network connection
• NAT (Network Address Translation) and Firewall features
• Approvals: CE, FCC, cULus
More security and flexibility for access to your facilities
Weidmüller Dual SIM industrial router with integrated VPN technology is ideally suited for secure remote access to components and systems in remote networks. Equipped with WLAN and 4G/LTE modules, two RJ45 Ethernet ports and a serial interface, Weidmüller security routers
ensure maximum connectivity – and due to their compact dimensions, they also save space in the control cabinet.
Typical Applications
The perfect choice for remote secured data communication from the factory floor PLCs, machines, networking devices and sensors. User has a possibility to choose between three different communication interfaces to connect the end-device through Fast Ethernet ports, Serial port, and Wireless Wi-Fi connectivity.
High Security. Reliable Mobile Connection.
To benefit from Industry 4.0, more and more machines, devices, and systems need to be networked. The prerequisites for this are mobile connectivity, secure network communication, and
powerful remote access. Our dual SIM security router, combined with our expert knowledge, provide the solution to this challenge.
- Integrated 4G/LTE modem with dual SIM option
- Reliable firewalling for secure protection of machines and systems
- Extensive IP address management for integrating series machines
- Clear WLAN interface – also for use as a service access point
Typical Industries:
• Machinery
• OEM
• Water Treatment
• Wind Energy
Weidmüller Industrial Security Routers
• Secure networks
• Stateful packet inspection Firewall
• IP/Port- forwarding
• Network segmentation
• Easy integration of machine networks into manufactur- ing networks through 1: 1 NAT
• Secure and easy remote maintenance with Weidmüller u-link remote access service
• Enable modular and future proof network architectures with static and dynamic routing
• Secure communication over the Internet by using IPsec and OpenVPN
• Reliable internet connection, even without on-site internet access, thanks to integrated 4G/LTE cellular mo-dem
• Full flexibility thanks to Fast Ethernet and Gigabit Ether-net interfaces ranging from 2 up to 4 ports.
General ordering data
| Version | Security/NAT/VPN/U-link Router, with integrated multi-band modem (4G/3G), US-model, Fast Ether-net, 2x RJ45 10/100BASE-T(X), 1x DB9 male for RS-232/422/485, IP30, -25 °C...70 °C |
| Order No. | 2682580000 |
| Type | IE-SR-2TX-WL-4G-US-V |
| GTIN (EAN) | 4050118692136 |
| Qty. | 1 pc(s). |
Data sheet
IE-SR-2TX-WL-4G-US-V
Technical data
Dimensions and weights
| Depth 81 mm | Depth (inches) 3.189 inch |
| Height 95 mm | Height (inches) 3.74 inch |
| Width 45 mm | Width (inches) 1.772 inch |
| Net weight 437 g |
Temperatures
| Storage temperature -40 °C...85 °C | Operating temperature -25 °C...70 °C |
| Humidity 5 to 95 % (non-condensing) |
Mobile radio interface
| Frequency band | LTE-FDD:, B2, B4, B5, B12, B13, B14, B66, B71, WCDMA: B2,B4,B5 |
| Transmission rate mobile radio | LTE category CAT 4 Download rate, max. 150 Mbit/s Upload rate, max. 50 Mbit/s |
| Wireless module | multi-band modem (4G/3G), Region:, North America |
EMC conformity and approvals
| EMC standards | EN 55032, EN 55024, FCC Part 15 Subpart B Class A, IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz bis 1 Ghz: 3 V/m, IEC 61000-4-4 EFT: Power: 0.5 kV; Signal: 0.5 kV, IEC 61000-4-5 Surge: Power: 0,5 kV; Signal: 1 kV, IEC 61000-4-6 CS: 3 Vrms |
Free fall | According to IEC 60068-2-31 |
| Safety standard | SELV according to EN 62368-1, UL 61010-1, UL 61010-2-201 |
Shock | according to IEC 60068-2-27 |
| Vibration | according to IEC 60068-2-6 |
Environmental conditions
| Humidity | 5 to 95 % (non-condensing) |
| Operating altitude | Altitude, max. 2,000 m Note in acc. with UL Altitude, max. 6,000 m Note for restrictions, see the manufacturer's declara- tion for operating altitude in section downloads |
| Operating temperature, max. | 70 °C |
| Operating temperature, min. | -25 °C |
| Storage temperature, max. | 85 °C |
| Storage temperature, min. | -40 °C |
Guarantee
| Time interval | 5 years |
Data sheet
IE-SR-2TX-WL-4G-US-V
Technical data
Interfaces
| Connector for external antennas | 2x SMA female, 1x RP- SMA female |
Digital inputs | 1x, 5 to 30 V for logic "1", 0 to 2 V for logic "0“ |
| Digital outputs | 1x, with a current capacity of 0.2 A at 30 VDC | Function reset button | <5 sec: System reboot and set LAN IP to factory Default, >5 sec: Factory default |
| Number of SIM-Card slots | 2 | Number of ports |
2x RJ45 10/100BASE- |
| SIM-Card slot type | Mini-SIM (ID-000 format) |
MTBF
| MTBF | According to Standard | Telcordia SR-332 |
| Operating time (hours), min. | 353,679 h |
Management features
| Device configuration | Webbrowser (HTTP/ HTTPS), SNMP v2c, Com- mand Line Interface (Tel- net/SSH), Upload of a con- figuration file via web-in- terface, SMS control com- mands |
Monitoring function | SNMP v2c, Syslog, Event based warning via E-Mail, Event based warning via relay, Event based warn- ing via SNMP trap, Event based warning via SMS, Device information and mobile radio status via SMS request |
| IP-address management | Static, DHCP-Client, DHCP-Server (pool-based), DHCP- Relay, DNS-Relay |
Security functions | Access Control List (MAC-based) for WLAN Access Point mode |
| Time synchronization management | NTP server, NTP client | Operating modes | WLAN Access Point, WLAN Client, Virtual COM mode, TCP Server mode, TCP Client mode, UDP Server/Client mode |
Power supply
| Connection type | 1 removable 4-pin terminal block |
| Current consumption | Voltage 12 V Current 0.46 A Voltage 24 V Current 0.22 A Voltage 48 V Current 0.11 A |
| Overload current protection | Yes |
| Reverse polarity protection | Yes |
| Voltage supply | 12/24/48 V DC, 2 redundant inputs, or 48 V DC Power-over-Ethernet (IEEE 802.3af) |
| Voltage supply range | Voltage type DC Voltage, min. 10.8 V Voltage, max. 52.8 V |
Data sheet
IE-SR-2TX-WL-4G-US-V
Technical data
Routing Features
| Firewall functions | Stateful Packet Inspection Firewall (Layer-3) |
NAT functions | Source / Destination NAT (Port / Host / Network) |
| Routing functions | IPv4 routing, Static and dy- namic IP Routing |
VPN functions | u-link client, OpenVPN (Server or Client), IPSec (Initiator or Responder) |
Serial communication parameters
| Baud rate | 110 bit/s to 460800 bit/s | Data bits | 7, 8 |
| Parity | none, odd, even, Mark, Space |
Stop bits | 1, 2 |
Technical data
| Housing main material | Metal | Protection degree | IP30 |
| Speed | Fast Ethernet | Type of mounting | DIN rail, Wall mounting |
Technology
| Standard | IEEE 802.3 for 10BASE-T, IEEE 802.3u for 100BASE- TX, IEEE 802.3af for Pow- er-over-Ethernet, IEEE 802.11b/g/n for Wireless LAN |
WLAN interface
| Data security | 64-bit and 128-bit WEP encryption, WPA/WPA2 Personal and Enterprise (IEEE 802.1X/RADIUS, TKIP and AES) |
| Transmission rate WLAN | Standard IEEE 802.11b max. 11 Mbit/s min. 1 Mbit/s Standard IEEE 802.11g max. 54 Mbit/s min. 6 Mbit/s Standard IEEE 802.11n max. 150 Mbit/s min. 6.5 Mbit/s |
Classifications
| ETIM 6.0 EC001478 | ETIM 7.0 EC001478 |
| ETIM 8.0 EC001478 | ETIM 9.0 EC001478 |
| ECLASS 9.0 19-17-01-03 | ECLASS 9.1 19-17-01-03 |
| ECLASS 10.0 19-17-04-05 | ECLASS 11.0 19-17-04-05 |
| ECLASS 12.0 19-17-04-05 | ECLASS 13.0 19-17-04-05 |
| ECLASS 14.0 19-17-04-05 |
Environmental Product Compliance
| RoHS Compliance Status | Compliant with exemption |
| RoHS Exemption (if applicable/known) | 6c, 7a, 7cI |
| REACH SVHC | Lead 7439-92-1 Lead monoxide 1317-36-8 |
| SCIP | 9229992a-00b9-4096-8962-200a7f33e289 |
Data sheet
IE-SR-2TX-WL-4G-US-V
Technical data
Important note
| Product information | Not compatible with the SCM card IE-EBR-SMARTCARD-SR 2909820000. |
