IDEC | 16IO CPU 24VDC Trans. Sink | FC6A-C16K1CE

51 in stock | Need More? >>

Ships same day if ordered M-F before 3PM PT.

Pickup Available at Livermore

Items that don't require customization purchased before 12 PM will be available the same business day. Items that require customization or are purchased after 12 PM will be available the next business day.

Key Features

  • 16I/O, 24VDC, Transistor Sink Output
  • Embedded Ethernet Port
  • Embedded SD memory port
  • Modbus TCP and RTU
  • Embedded RS232C/RS485 user selectable
  • Maximum 400 digital I/O
  • Maximum 100 analog I/O
  • Data Logging
  • Web Server Functions
  • Large programming and data memory
  • cULus CE Class 1 Div 2

Hardware Specifications

Embedded Digital IO 16
SD Memory Slot true
USB Port USB Mini-B
Number of Ethernet Port 1
Embedded Analog IO 1
Embedded Serial Port 1
Number of Embedded Input 9
Digital Output Type Relay

Electrical Specifications

Operating voltage 24VDC

Performance Specifications

Internal relay 12400
Maximum Digital I/O Points 404
Data register 56000
Maximum Analog I/O Points 101
Maximum number of expansion modules 12
Timer 1024

Operation Specifications

Program Capacity 384K Bytes
High-speed Counter 100 Khz
Analog Input Type 0-10 VDC
Communication Protocol Modbus RTU
Modbus TCP
Programming Language Ladder, Script
Number of Embedded Output 7
iOS and Android App WindEDIT Lite
Battery BR2032
Maximum Expandable Serial Ports 7

Certification Specifications


UL certification Yes
CE marking Yes
Hazardous Location Class I Div 2

Environmental Specifications

Operating Temperature -25 to 65 deg. C

Mechanical Specifications

Product Type CPU Base Module
Terminal Shape Screw terminal

ID #: 144029
