side view of a corner bracket with an oval hole on one side and a round hole on the other side

diagram of a corner bracket

diagram of a corner bracket mounted to a t-slot bar

80/20 | 40 Series Panel Mount Bracket | 40-2430

$4.87

Mfr. Part #: 40-2430

Pickup Available at Livermore

ID #: 27463

Description
Resources

The panel mount bracket is used to mount a panel flush with a profile and has a slotted hole which allows for greater adjustability when mounting the panel. It engages the 2-degree drop-lock feature when the assembly bolts are tightened to the required torque. The panel mount bracket is a fastening method that can be repositioned and reused. The panel requires a through hole as well as hardware to mount the panel to the bracket, which should be based on the panel type and thickness.
Product Resources

STEP file

Download Step File
