wide, metal, inside corner bracket, with a larger side on the bottom, and six mounting holes

diagram of an inside corner bracket

diagram of an inside corner bracket with screws

80/20 | 10 Series 6 Hole - Wide 2x4 Inside Corner Bracket | 4175

$7.91

Pickup Available at Livermore

ID #: 30356

Description
Resources

The 6 hole - wide 2x4 inside corner bracket is an external fastening method that creates a 90 degree connection. One side of the bracket has two adjacent holes and the second side has four holes comprised of two rows and two columns. This fastener requires no machining services and can provide infinite positioning along the profile T-slot, allowing a large degree of adjustability. It engages the 2-degree drop-lock feature when the assembly bolts are tightened to the required torque and can also be repositioned and reused.
Product Resources

STEP file

Download Step File
