Analogue Signal Processing Reliable signal processing is crucial for your systems.
With us, your signals are in safe hands.
Advantages of using signal conditioners
Your benefits with analogue signal converters from Weidmüller:
- Comprehensive range of analogue signal conditioners for every application
- Absolutely reliable signal transmission – even in hazardous environments or those with a high level of electromagnetic interference
- Simple and fast product configuration with intelligent FDT/DTM software tools
- Optimum product selection thanks to convenient online product assistant
- Wide range of complementary solutions – from sensors to the cloud
- Individual support through internationally available consulting and services
Secure and reliable transmission of analogue signals
Industrial signal conditioners from Weidmüller.
Data is key to optimizing industrial processes, making important business decisions, and more. Increasingly, machines and systems are equipped with sensors to record parameters such as temperature, pressure, filling level, flow rates, weight, or speed. Signal conditioners are essential to ensure this analogue data is reliable for use with the intended application. They enable reliable transmission of analogue sensor signals – the foundation of any value-added data processing.
As a partner in Industrial Connectivity, Weidmüller understands the conditions across various industrial sectors. Our signal converters are designed to ensure optimum signal transmission and conversion under all circumstances. Selected components are used to prevent factors like temperature fluctuations, electromagnetic interference, vibrations, and corrosive or explosive atmospheres from affecting the safety and accuracy of signal transmission. So, your signal is always in safe hands. We continuously develop our broad product range to equip you for the future.
Made to meet your challenges:
Our signal processing for various industries
Whether in mechanical engineering, the process industry, or power engineering, no application today can do without electronics and electrical connectivity. The complexity of electrotechnical and electronic components is influenced by advancements in digitalization, technological changes, and internationalization. With our portfolio of analogue signal converters, we ensure reliable and secure signal transmission, constantly adapting to today’s rapidly changing markets.
Mechanical engineering – precise and compact
To support signal acquisition in extreme environments, our ACT20P signal converters are the right choice. These process and transmit analogue data with an accuracy of up to 0.05%. For maximizing space, our ACT20M series offers up to 2 channels with a width of just 6 mm. The MCZ family of signal converters is even more compact, currently being the smallest on the market with a height of only 52 mm.
Process industry – communicative and safe
Our intrinsically safe ACT20X signal converters with FDT/DTM support are ideal for complying with high standards of explosion protection and functional safety. These converters complement integrated safety systems up to a SIL level of 3.
Power – precise and functional
In power engineering, one of the greatest challenges is the reliable and precise isolation of control signals from high power levels. Our signal converters from the ACT20P and ACT20M families excel in these tasks, offering useful functions such as signal doubling or limit value determination. The ACT20C series also enables continuous monitoring of device and system functions.
Seven good reasons for using signal conditioners
Our analogue signal converters in your applications:
1. Earth Loop Isolation
A signal isolator interrupts the earth loop, making the installation of field devices independent of the earthing and shielding concepts of the installed PLC/DCS system.
2. Protection against EMC Interference
Input filters in signal conditioners block electromagnetic interference, ensuring the desired process values can be determined without interference.
3. Protection against Dangerous AC Voltages
Isolating amplifiers ensure reliable isolation in the event of a fault, providing secure galvanic isolation between inputs, outputs, and power supply connections.
4. Protection against Short Circuits in Signal Wiring
Active and passive isolating amplifiers isolate the input channels from the measuring transducer, ensuring that short circuits within one signal circuit do not affect neighboring circuits.
5. Signal Conversion into Standard Signals
Signal converters convert, amplify, and linearize physical input signals, mapping them to standard signals for further processing.
6. Splitting Signals between Receivers
Isolating signal splitters decouple the sensor from the load of multiple receivers, preventing sensor overload.
7. Matching Current Sources to Inputs
Passive isolating amplifiers match active outputs to active inputs, with an output loop powered isolating amplifier (OLP) requiring no additional power supply.
You have individual requirements. We have a flexible product range.
No matter what your requirements are, our ACT20 series analogue signal converters ensure secure and precise signal conversion and isolation. They are suitable for a wide variety of applications, offering specific properties such as communication capability, compact dimensions, and software configurability. With all these benefits, your analogue signal is always in safe hands.
ACT20P: The flexible solution
- Precise and highly functional signal converter series
- Easy configuration with display, FDT/DTM software, or DIP switches
- Convenient release lever for uncomplicated handling
- Space-saving design with widths from 12.5 mm for two channels
ACT20X: The intrinsically safe solution
- Wide range of functions for separating and conditioning intrinsically safe signals
- Compliance with strict process industry standards – approved for Ex zones and SIL capability
- Simple configuration via FDT/DTM software
ACT20C: The connective solution
- Communication-enabled interface for status monitoring and diagnostics
- FDT/DTM software for configuration via Ethernet – local or remote access
- Can function as a communication-enabled station with Plug and Produce function
MCZ: The smallest solution
- The smallest terminal block-sized analogue signal converter on the market
- Maximum space savings due to a compact design with a width of 6 mm
- Reliable conversion of analogue signals
- Quick and easy wiring via pluggable cross-connectors
Process value indicators
- Easy-to-read four-digit LED or LCD displays
- Large 1/8” display according to DIN standard
- Weather-resistant front panel with IP65 protection
- Integrated signal converter and limit switch
ACT20M: The slim solution
- Safe isolation and conversion with a width of only 6 mm
- Direct power supply via CH20M mounting rail bus
- Easy configuration via DIP switches or FDT/DTM software
- Extensive approvals such as ATEX, IECEX, GL, DNV
- Particularly robust and insensitive to interference
Exploit all the possibilities offered by our products
Our Support Center offers comprehensive personal assistance
Explore the world of our new Support Center:
- Everything at a glance: All relevant information is available to you at all times on a central service platform.
- Powerful search: Clever filter functions make it easy for you to find information and products quickly.
- User-friendly navigation: All relevant content, product information, software downloads, and technical support are just a few clicks away.
- Large download area: Access to 170,000 files including application notes, video tutorials, templates, examples, user documentation, and more.
- Personal contact: Get in touch with your personal technical contact whenever you need.
Explore: support.weidmueller.com
The easy way from data to value
Our Industrial IoT portfolio
The journey to Industrial IoT doesn’t have to be complicated. Whether you need access to valuable data or want to offer new data-driven services, we pave the way for our customers to go from data to value. Our extensive, future-oriented IIoT portfolio is suitable for both greenfield and brownfield applications, providing components and solutions for data acquisition, pre-processing, communication, and analysis.
Your benefits at a glance:
- Simple and fast retrofitting of IoT solutions
- Open and web-based engineering
- A competitive edge for the future
Digital Engineering – intuitive, uncomplicated, fast
The Weidmüller Configurator
Digital engineering has never been easier! Create your own configuration from over 10,000 Weidmüller digital products. The Weidmüller Configurator supports you in every step of the process, seamlessly bridging planning to operation and treating panel building as a single process.
Your benefits at a glance:
- Provision of intelligent item data
- Simple and secure ordering process
- Always the right configuration
- Fast and easy product enquiry
