VacMotion | 41mm 4.5 bellows Silicone suction cup | PMB40-SIR

Mfr. Part #: PMB40-SIR

Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.

ID #: 222204

41 mm, 4.5-bellows silicone suction cup designed for vacuum handling and bag-handling applications. The multiple-bellows construction provides flexibility for uneven surfaces and height differences while helping provide a lifting movement for separating thin or deformable materials. Silicone construction offers good wear and oil resistance with excellent weather and ozone resistance.

Compatible Products: Recommended replacement cups include BL40-2.20.04AC and 0101536. Compatible fittings include 1/4" NPT male with filter screen (402.012), which is available for the PMB40-SIR series.
Feature Set
• 4.5-bellows design

• Silicone construction

• Good wear resistance

• Good oil resistance

• Excellent weather and ozone resistance

• Wide temperature range

• Multiple compatible fittings

• Multiple interchangeable replacements available

Specification	Details
Style	Bellows
Material	Silicone
Outside Diameter	41.0 mm
Bellows	4.5
Thread Size	None
Cleats	No
Color	Red
Weight	0.033 lbs.
Fitting Included	No
Horizontal Lifting Capacity at 6 inHg	2.45 lbs.
Vertical Lifting Capacity at 6 inHg	1.22 lbs.
Horizontal Lifting Capacity at 18 inHg	7.36 lbs.
Vertical Lifting Capacity at 18 inHg	3.68 lbs.
Horizontal Lifting Capacity at 27 inHg	11.05 lbs.
Vertical Lifting Capacity at 27 inHg	5.52 lbs.
Wear Resistance	Good
Oil Resistance	Good
Weather & Ozone Resistance	Excellent
Temperature Range	-94 to 392 °F (-70 to 200 °C)
