Mfr. Part #: 48250401
Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.
ID #: 194227
The Socomec SIRCO M Series Rotary Disconnect Switch is a high-performance, load break-capable switch designed for industrial applications. This 3-pole switch operates at 600 VAC with a 25A rating and features a 65kA Short-Circuit Current Rating (SCCR) for reliable protection against short circuits. It is suitable for DIN rail or panel mounting, providing flexibility for various installation setups. The switch is UL 508 rated, ensuring compliance with industry safety standards. It can be operated from either the front or side and accepts a 5 x 5mm shaft, offering compatibility with a wide range of actuators. Ideal for isolating power in control panels or electrical systems, this switch delivers durability, safety, and versatility.
| Specification | Details |
|---|---|
| Brand | Socomec |
| Item | Disconnect switch |
| Series | SIRCO M |
| Fusible | No |
| Load Break Capable | Yes |
| Number of Poles | 3 |
| Voltage Rating | 600 VAC |
| Amperage Rating | 25A |
| SCCR Rating | 65kA SCCR |
| Mounting | DIN rail or panel |
| UL Rating | UL 508 rated |
| Configuration | Front or side operated |
| Shaft Size | Accepts 5 x 5mm size shaft |
| Handle Type | Rotary |
