PPS1 4C20
45° - 3/4" Aluminum equal female elbow fitting
|
For pipe OD (in)
|
3/4" |
| Technology |
PPS Grip Concept
|
|
Operating pressure
|
0 to 232 psi
|
|
Vacuum capability
|
-29 inHg (vacuum 98%)
|
|
Temperature
|
-4°F to +176°F
|
|
Construction
|
Pipe and fittings: aluminum
|
| Highlight |
Scalable system
|
|
Meets standards
|
ASME B31.3 REACH
|
| Dimensions | |||
| Reference | A inch | B inch | C inch |
| PPS1 4C16 | 1.26 | 2.756 | 1.969 |
| PPS1 4C20 | 1.496 | 3.268 | 2.323 |
| PPS1 4C25 | 1.811 | 3.858 | 2.756 |
| PPS1 4C32 | 2.244 | 4.606 | 3.346 |
| PPS1 4C40 | 2.677 | 5.512 | 4.016 |
ID #: 195815
