Mfr. Part #: 103-493
ID #: 139471
The Mark 3 Series offers high flow in a miniature valve design. The Mark 3 line is available with 10-32 or 1/8" porting in either sub-base or manifold mounting, sandwich speed control and sandwich pressure regulators.
| Specifications | |
| CV | 0.35 |
| Port sizes | 1/8" FNPT & G, 10-32, M5 |
| Ports | 5 Ported, 2 and 3 position, 4-way, spool & sleeve |
| Flow Capacity | 8.34-16.21 scfm @ 80 psig / 177-345 NI/M @ 6 Bar |
| Operating Pressure Range | 28 HG vacuum to 150 psig / vacuum to 10 Bar |
| Pilot Pressure Range | 20-100PSIG/ 2 position detented 15-100PSIG |
| Temperature Range | -10F to +115F (-23C to +46C)/ Air Pilot 200F (93C) |
