Mfr. Part #: Ex9S32A14A
Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.
ID #: 184876
Thermal-magnetic Manual Motor Starter (MMS) - 1600056 - Ex9S32 - 9-14A setting - class 10 - rotary handle operation
| Specification | Details |
|---|---|
| Primary Brand | NOARK |
| Main Function | Thermal-magnetic Manual Motor Starter (MMS) / Branch protector |
| Sub-range Name | Ex9S32 series |
| Current Setting Range | 9A...14A |
| Interrupting Capacity | 65kA (type E; 240Vac; 480Y/277Vac) |
| Operating Mode | Rotary handle operation |
| Poles | 3-poles (3P) |
| Connection Type | M4 slotted head screw connections |
| Trip Unit Type | Thermal-Magnetic (adjustable) |
| Degree of Protection | IP20 |
| Technical Compatibility | Compatible with Ex9S32 motor starter |
| Equivalent to | 1600056 |
