Lenze | i550 Power Unit, 5 HP 3ph 480V IP20 EMC filter | I5DBE240F10V10000S

Name: Lenze | i550 Power Unit, 5 HP 3ph 480V IP20 EMC filter | I5DBE240F10V10000S
Brand: Lenze Americas
SKU: I5DBE240F10V10000S
Price: 870.97 USD
Availability: InStock

Mfr. Part #: I5DBE240F10V10000S

Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.

Pickup Available at Livermore

The Lenze I5DBE240F10V10000S is a 4.0 kW frequency inverter offering versatile motor control with multiple communication options and safety features. Ideal for conveyors, pumps, fans, and packaging systems.

Key Features:
- Rated Power: 4.0 kW / 5.5 HP
- Input Voltage: 3-phase 400–480 VAC
- Enclosure Rating: IP20 (Control Cabinet Mount)
- Control Modes: V/f (linear/quadratic), Sensorless Vector, SC-ASM (Servo Control)
- Integrated EMC Filter
- Overload Capacity: 200% for 3 seconds, 150% for 60 seconds
- I/O Configuration: 5 Digital Inputs, 1 Digital Output, 2 Analog Inputs, 1 Analog Output
- Communication Options: CANopen, EtherCAT, EtherNet/IP, Modbus RTU, PROFIBUS, PROFINET, IO-Link
- Safety Features: Optional Safe Torque Off (STO, SIL 3 / PL e)
- Approvals: CE, UL, CSA, EAC, RoHS
- Operating Temperature: -10°C to +50°C

Common Applications:
- Conveyor Drives
- Pump Systems
- Fan Control
- Packaging Machines
- HVAC Systems

Lenze I5DBE240F10V10000S Specifications
Model	I5DBE240F10V10000S
Power Rating	4.0 kW / 5.5 HP
Input Voltage	3-phase 400–480 VAC
Enclosure	IP20 (Control Cabinet Mount)
Control Modes	V/f (linear/quadratic), Sensorless Vector, SC-ASM (Servo Control)
Overload Capacity	200% for 3 seconds, 150% for 60 seconds
I/O Configuration	5 Digital Inputs, 1 Digital Output, 2 Analog Inputs, 1 Analog Output
Communication Options	CANopen, EtherCAT, EtherNet/IP, Modbus RTU, PROFIBUS, PROFINET, IO-Link
Safety Features	Optional Safe Torque Off (STO, SIL 3 / PL e)
Approvals	CE, UL, CSA, EAC, RoHS
Operating Temperature	-10°C to +50°C
