Mfr. Part #: I55AE222F10V11000S
Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.
The Lenze I55AE222F10V11000S is a compact, cabinet-mounted frequency inverter from the i550 series, designed for efficient motor control in space-constrained industrial environments. Rated at 3 HP (2.2 kW), this VFD supports advanced control modes such as V/f, sensorless vector, and energy-saving VFC-ECO. With modular connectivity options for all major fieldbus protocols and built-in safety features like Safe Torque Off (STO), it’s ideal for applications like pumps, fans, conveyors, and OEM automation systems requiring precision, reliability, and scalability.
| Lenze I55AE222F10V11000S – Specifications | |
|---|---|
| Product Type | Frequency Inverter (Variable Frequency Drive) |
| Series | i550 Cabinet Series |
| Part Number | I55AE222F10V11000S |
| Power Rating | 3 HP / 2.2 kW |
| Input Voltage | Three-phase, 400–480 VAC |
| Control Modes | V/f (linear/quadratic), Sensorless Vector, VFC-ECO, Servo, DC Braking, Flying Restart |
| Communication Protocols | Modbus RTU/TCP, EtherCAT, EtherNet/IP, CANopen, PROFINET, PROFIBUS, IO-Link (via modules) |
| Mounting Type | Cabinet Mount (Slim Design) |
| Protection Rating | IP20 |
| Ambient Operating Temperature | −10 °C to +50 °C (derating may apply) |
| Integrated Features | EMC Filter, Conformal Coating, STO (Safe Torque Off), Diagnostics LEDs |
| Dimensions (W × D) | Approx. 60 mm × 130 mm |
| Configuration | Via EASY Starter (PC) or Smartphone App (with module) |
| Common Applications | Pumps, fans, conveyors, packaging equipment, HVAC, OEM automation systems |
ID #: 197746
