IDEC | Micro PLC | FC6A-C16P1CE

10 in stock | Need More? >>

Ships same day if ordered M-F before 3PM PT.

Pickup Available at Livermore

Items that don't require customization purchased before 12 PM will be available the same business day. Items that require customization or are purchased after 12 PM will be available the next business day.
  • 16I/O, 24VDC, Transistor Souce Output
  • Embedded Ethernet Port
  • Embedded SD memory port
  • Modbus TCP and RTU
  • Embedded RS232C/RS485 user selectable
  • Maximum 400 digital I/O
  • Maximum 100 analog I/O
  • Data Logging
  • Web Server Functions
  • Large programming and data memory
  • cULus CE Class 1 Div
  •

    Certification Specifications

    IP Rating IP20
    UL certification Yes
    TUV certification Yes
    CE marking Yes
    Hazardous Location Class I Div 2

    Hardware Specifications

    Embedded Digital IO 16
    SD Memory Slot true
    USB Port USB Mini-B
    Number of Ethernet Port 1
    Embedded Analog IO 1
    Embedded Serial Port 1
    Number of Embedded Input 9
    Digital Output Type Transistor Source

    Electrical Specifications

    Operating voltage 24VDC

    Performance Specifications

    Internal relay 12400
    Maximum Digital I/O Points 404
    Data register 56000
    Maximum Analog I/O Points 101
    Maximum number of expansion modules 12
    Timer 1024

    Operation Specifications

    Program Capacity 384K Bytes
    High-speed Counter 100 Khz
    Analog Input Type 0-10 VDC
    Communication Protocol Modbus RTU
    Modbus TCP
    Programming Language Ladder, Script
    Number of Embedded Output 7
    iOS and Android App WindEDIT Lite
    Battery BR2032
    Maximum Expandable Serial Ports 7

    Environmental Specifications

    Operating Temperature -25 to 65 deg. C

    Mechanical Specifications

    Product Type CPU Base Module
    Terminal Shape Screw terminal

    ID #: 146904
