Mfr. Part #: HSP-1001-6-5
Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.
The Dynamic Fluid Components BMPH-400-H2-K-P is a low-speed, high-torque hydraulic motor designed for demanding hydraulic drive applications. Featuring a 387 cc/rev displacement and a compact, efficient gerotor design, this motor delivers up to 4,337 in-lb of continuous torque at speeds up to 155 RPM. Its SAE A two-bolt mounting flange, 1-inch Woodruff-keyed shaft, and 1/2-inch NPTF ports provide a practical configuration for industrial and mobile hydraulic systems. The BMPH series supports both parallel and series hydraulic circuit configurations, offering flexibility for a range of equipment and power transmission applications.
| Manufacturer | Dynamic Fluid Components |
| Part Number | BMPH-400-H2-K-P |
| Motor Type | Gerotor Hydraulic Motor |
| Displacement | 387 cc/rev (23.61 in³/rev) |
| Maximum Continuous Speed | 155 RPM |
| Maximum Intermittent Speed | 190 RPM |
| Maximum Continuous Torque | 4,337 in-lb |
| Maximum Intermittent Torque | 5,133 in-lb |
| Maximum Continuous Differential Pressure | 1,450 PSI |
| Maximum Intermittent Differential Pressure | 1,813 PSI |
| Maximum Continuous Flow | 15.85 GPM |
| Maximum Intermittent Flow | 19.82 GPM |
| Mounting | SAE A 2-Bolt Flange |
| Shaft | 1-inch Woodruff-Keyed Shaft |
| Ports | 1/2-inch NPTF |
| Port Location | Side-Ported |
| Weight | 17.75 lb |
ID #: 223585
