The Type 700 is designed for applications that require high flow capacity and accurate process control. A poppet valve which is balanced by utilizing a rolling diaphragm insures a constant output pressure even during wide supply pressure variations. Stability of regulated pressure is maintained under varying flow conditions through the use of an aspirator tube which adjusts the air supply in accordance with the flow velocity
Specifications | |
Port Size | 1/2" NPT |
Output Range | 0-150 psi (0-10 Bar) |
Flow Capacity | 80 scfm (2,264 Nl/min) |
Exhaust Capacity | 4 scfm (120 NL/min) |
Sensitivity | 1/8" in. (3.2 mm) |
Effective of Supply Pressure Variation on Output | Less than 0.1 psi (.007 Bar) for 100 psi (6.7 Bar) change |
Air Consumption | Steady State: From 1.0 to 12.5 scfh (30 to 375 Nl/hr), depending on output pressure range |
Supply Pressure | 250 psig (17.5 BAR) Maximum |
Operating Temperture | -40° to +160°F '(-40° to 71°C) |
Weight | 1 lb, 10 oz (.74 kg) |
Mounting | Pipe, Panel, Bracket |
Body Material | Diecast Aluminum Alloy |
Other Material | Stainless steel, Brass, Plated Steel Acetal, Buna-N, Polyester, Phenolic Plastic |
ID #: 53790
