Name: Control Air | Reg 0-2 PSi High Flow | 700-BA
Brand: ControlAir LLC
SKU: 700-BA
Price: 135.68 USD
Availability: OutOfStock

Mfr. Part #: 700-BA

Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.

ID #: 28484

700-BA precision air regulator, 1/4" NPT, 0-2 PSI. High flow, 250 psig max, for lab, calibration, and low-pressure control.
Key Features:
• High flow precision air pressure regulator from ControlAir Type 700 series
• 1/4" NPT ports with 0-2 PSI (0-0.14 bar) output range for low pressure applications
• Max supply pressure: 250 psig (17 bar); exhaust capacity: 4 scfm
• Sensitivity: 1/8" (3.2 mm) water column for accurate regulation
• Operating temperature: -40°C to 71°C (-40°F to 160°F); balanced valve design minimizes supply pressure effects

Common Applications:
• Precision pneumatic pressure control in laboratory and test equipment
• Low pressure regulation for air bearings and sensitive actuators
• Calibration systems and instrumentation in industrial automation
• Process control in manufacturing and aerospace pneumatic circuits

Specifications - 700-BA
Model	700-BA
Type	High Flow Precision Air Pressure Regulator
Port Size	1/4" NPT
Output Range	0-2 PSI (0-0.14 bar)
Max Supply Pressure	250 psig (17 bar)
Exhaust Capacity	4 scfm
Sensitivity	1/8" (3.2 mm) water column
Operating Temperature	-40°C to 71°C (-40°F to 160°F)
Design	Balanced Valve
Applications	Laboratory equipment, test systems, air bearings, calibration, instrumentation, process control
