Alkon | DOT, PUSH-IN ELBOW MALE, SWIVEL 1/2 IN TUBE X 1/2 IN NPT | AQ69-DOTS-8X8

Name: Alkon | DOT, PUSH-IN ELBOW MALE, SWIVEL 1/2 IN TUBE X 1/2 IN NPT | AQ69-DOTS-8X8
Brand: ALKON CORPORATION
SKU: AQ69-DOTS-8X8
Price: 17.48 USD
Availability: InStock

Mfr. Part #: AQ69-DOTS-8X8

Ships same day with standard 2-day shipping if ordered M-F before 3PM PT.

Pickup Available at Livermore

Quantity	Discount	Part Price
>10 pieces	10.0 %	$15.73

ID #: 213600

Description
Features
Specifications
Resources

AQ69-DOTS-8X8 union elbow, 1/2″ tube push-to-connect fitting. DOT-approved brass connector for air brake and heavy-duty pneumatic systems.
Key Features:
• Male branch tee fitting from Alkon AQ-DOT series
• Push-to-connect 3/8" OD tube ports (two inlets) and a 1/4" NPT male threaded outlet
• Brass construction with pre-applied thread sealant for secure, leak-resistant connections
• Compact size (~1.31" length) with swivel capability for flexible installation
• Temperature range: -40 °F to 212 °F; meets DOT FMVSS 571.106 standards

Common Applications:
• Branching pneumatic tubing in vehicle air brake systems
• Flexible routing in confined or modular pneumatic setups
• OEM and heavy-duty systems requiring DOT-compliant, secure pneumatic fittings

Specifications - AQ69-DOTS-8X8
Model	AQ69-DOTS-8X8
Fitting Type	Union Elbow, Push-to-Connect
Tubing Size	1/2″ OD Tube (both ports)
Material	Brass with Corrosion-Resistant Finish
Sealing	Integrated O-ring Seal
Operating Temperature	-40 °F to 212 °F
Compliance	DOT FMVSS 571.106 Approved
Applications	Vehicle air brake systems, heavy-duty trucks, trailers, and pneumatic control lines
