black hinge unit with a covered rectagular piece on the left side, a cylindrical hinge piece in the center, and an uncovered rectangular piece on the right with two mounting holes showing, and the cover sitting below

diagram of a hinge unit

diagram of a hinge unit

80/20 | 15 & 40 Series 4 Hole - Detent Positioning Hinge | 12327

$19.57

Mfr. Part #: 12327

Pickup Available at Livermore

ID #: 66190

Description
Resources

The 4 hole - detent positioning hinge is commonly used to connect plastic panels to profiles or to connect two profiles together. It holds doors open at 0, 85 or 175 degrees and is especially useful in horizontal-lifting applications, as it provides hands-free access. It has snap-on covers that hide the hardware for a clean appearance and a detent hinge stopper which includes the mounting hardware.
Product Resources

STEP file

Download Step File
