Low Profile Electric Slider: EW2G Series

The EW2G Low Profile Electric Slider is designed to deliver high rigidity and high accuracy in a compact form. It is the first actuator in the industry to offer low profile with high rigidity, making it a versatile solution for applications that require precise motion control.

Key Features:

• Compact and High-Rigidity Design: The EW2G combines a compact DC brushless motor with Koganei’s highly reliable Mini Guide Slider series, offering low profile while maintaining excellent rigidity and accuracy.

• High Accuracy Positioning: With a repeatability of stopping accuracy of ±0.005 mm (when using an external stopper), the EW2G guarantees precise positioning for a wide range of applications.

• Intermediate Stops, Speed Control, and Thrust Settings: The system allows for flexible operation with features such as intermediate stops and speed control. External stopper usage provides stroke adjustment mechanisms for highly accurate movement.

• Simple Control: It offers a straightforward ON/OFF control mode, similar to that of an air cylinder, making it easy to operate.

• Precision Movement:

  • Travel Parallelism: 0.005 mm [0.0002 in.]
  • Mounting Parallelism: 0.03 mm [0.001 in.]

Specifications:

• Motor Sizes:

  • EW2G10: Motor size 10 [0.394 in.]
  • EW2G12: Motor size 12 [0.472 in.]
  • EW2G16: Motor size 16 [0.630 in.]

• Maximum Thrust:

  • φ10: 20 N [4.496 lbf]
  • φ12: 40 N [8.992 lbf]
  • φ16: 60 N [13.488 lbf]

• Maximum Speed: 100 mm/s [3.937 in/sec]

Available Variations:

1. Standard Specifications (EW2G□)
2. Bracket Mounting Options:
   • EW2G-BK1: Bracket 1
   • EW2G-BK2: Bracket 2
   • EW2G-BK3: Bracket 3
3. Cover Specifications (EW2G□C)
4. Fixed Table Specifications (EW2G□R)

Stroke Adjustment Mechanisms:

• Customers may add stroke adjustment mechanisms like metal stoppers for finer control.

Allowable Moments (for EW2G16):

• Pitching: 2.1 N·m [18.587 in·lbf]
• Yawing: 2.5 N·m [22.128 in·lbf]
• Rolling: 4.3 N·m [38.059 in·lbf]

Mounting Options:

• Three brackets available for vertical mounting of the actuator.
• Stroke length options range from 10 mm to 100 mm, with different configurations depending on the motor size and stroke length.

Environment Considerations:

• Measures against foreign objects are available in certain configurations, but not in the EW2G□R fixed table specification.

This slider is ideal for applications that demand high-precision and compact design while maintaining robust performance and reliability in various industrial settings.
