Ultra-compact Inclination Sensors GIM140R
Less Space Consumption – More Performance
- High Protection
- Low Temperatures
- Extremely High EMC Immunity
Product Overview GIM140R
Technical Modifications and Errors Reserved.
09/20 No. 11235858
GIM140R Models:
| Model | 1-Dimensional | 2-Dimensional |
|---|---|---|
| Sensing Method | MEMS | MEMS |
| Size (Housing) | 48 x 14 x 45 mm | 48 x 14 x 45 mm |
| Measuring Range | 0 ... 30° / 0 ... 60° / 0 ... 90° / 0 ... 120° / 0 ... 180° / 0 ... 270° / 0 ... 360° | ±10° / ±30° / ±45° / ±60° |
| Voltage Supply / Interface | 8 ... 30 VDC / Analog 0.5 ... 4.5 VDC | 12 ... 30 VDC / Analog 0 ... 10 VDC / 12 ... 30 VDC / Analog 4 ... 20 mA / 8 ... 36 VDC / CANopen® / 8 ... 36 VDC / CANopen® redundant (2-channel architecture) |
| Resolution | Up to 0.1° | Up to 0.05° |
| Accuracy (+25°C) | Up to ±0.2° | Up to ±0.2° |
| Operating Temperature | -40 ... +85 °C | -40 ... +85 °C |
| Material | Housing: Aluminum, anodized | Housing: Aluminum, anodized |
| Protection | DIN EN 60529 IP 67 / IP 69K | DIN EN 60529 IP 67 / IP 69K |
| Connection Cable | 0.3 m (5 x 0.5 mm²) Resilient 0.5 mm² core cross section | Matching cables with mobile automation connection technology (e.g., DEUTSCH / AMP) |
| Comfort Functions | User-configurable low-pass filter | Integrated terminating resistor / Teach input for zero position adjustment / Innovative output characteristics for out-of-range diagnostics |
Technical Features & Functions:
- User-configurable low-pass filter
- Integrated terminating resistor
- Teach input for zero position adjustment
- Innovative output characteristics for out-of-range diagnostics
